Polyester Hlau Mesh

Polyester Hlau Mesh

Polyester Spiral Press Filter Fabrics yog siv rau hauv daim ntawv ua, luam ntawv thiab dyeing, khoom noj khoom haus thiab kua-kua sib cais industrial.

Xa kev nug
  • Kev xa khoom sai
  • Quality Assurance
  • 24/7 Kev Pabcuam Cov Neeg Siv Khoom
Khoom Taw qhia

Polyester Spiral Press Filter Fabrics


Pic.15 Polyester Spiral Press Filter Fabrics


Daim ntawv thov:

Polyester Spiral Press Filter Fabrics yog siv rau hauv daim ntawv ua, luam ntawv thiab dyeing, khoom noj khoom haus thiab kua-kua sib cais industrial.


Table 7 Specifications ntawm Kauv Lim Fabrics

Hom

Hom No.

Hlau Dia.(mm)

Lub zog

Permeability (m3 / m2h)

Warp

Welf

Filler

Loj loj

LWB 4080 IV

0.90

1.10

0.90*4

Ntau dua lossis sib npaug li 2300

10235±500

lwv 4080v

0.90

1.10

0.90*5

Ntau dua lossis sib npaug li 2300

6317±500

Nruab nrab voj

LWB 3868 III

0.70

0.90

0.80*3

Ntau dua lossis sib npaug li 2000

10320±500

LWB 3868 IV

0.70

0.90

0.80*4

Ntau dua lossis sib npaug li 2000

8500±500

Micro voj

LWM 3252 III

0.52

0.70

0.68*3

Ntau dua lossis sib npaug rau 1800

2850±500

Nruab nrab voj
(Plat hlau)

lwv 3868j

0.70

0.70

0.24*0.85

Ntau dua lossis sib npaug li 2000

10100±500


Polyester Spiral Dryer Fabrics


Pic.15 Polyester Spiral Dryer Fabrics


Daim ntawv thov:

Nws yog tsim rau ziab packing ntawv, kab lis kev cai ntawv, board ntawv thiab pulp board


Table 8 Specifications of Spiral Drier Fabrics

Hom

Hom No.

Hlau Dia.(mm)

Lub zog

Permeability (m3 / m2h)

Warp

Welf

Lub voj voog

lwv 90110

0.90

1.10

Ntau dua lossis sib npaug li 2300

21000±500

Loj loj

lwv 4080

0.40

0.80

Ntau dua lossis sib npaug li 2000

18000±500

Nruab nrab voj

lwv 3868

0.38

0.68

Ntau dua lossis sib npaug li 2000

16000±500

Zoo voj

lwv 3560

0.35

0.60

Ntau dua lossis sib npaug li 2000

15000±500

Micro voj

lwv 3252

0.32

0.52

Ntau dua lossis sib npaug rau 1800

15000±500


Polyester Plain Dryer Fabrics


Pic.16 Polyester Plain Dryer Fabrics


Daim ntawv thov:

Lub tshuab ziab khaub ncaws hauv daim ntawv ua kev lag luam. Kev ua tau zoo ntawm lub sijhawm thiab kev ruaj ntseg yog qhov tseem ceeb heev rau kev tsim khoom.


Table 9 Specifications of Plain Drier Fabrics

Hom

Hom No.

Hlau Dia.(mm)

Lub zog

Permeability (m3 / m2h)

Warp

Hlau / cm

Welf

Hlau / cm

3 lub series

22503

0.50

24

0.50

12

Ntau dua lossis sib npaug li 2000

8000±500

4 lub series

20504

0.50

22

0.50

12

Ntau dua lossis sib npaug rau 1900

13000±500

22504

0.50

24

0.50

12

Ntau dua lossis sib npaug li 2000

12000±500

24504

0.50

26

0.50

12

Ntau dua lossis sib npaug rau 2100

11000±500

Round Hlau Npuag

4106

0.50

22

0.50

12.4

Ntau dua lossis sib npaug li 2000

6800±500


Polyester Plain Fabrics

image009image008
Pic.17 & 18 Polyester Plain Fabrics


Daim ntawv thov:

Lub tshuab ziab khaub ncaws hauv daim ntawv ua kev lag luam thiab ntoo vaj huam sib luag tsim kev lag luam.


Table 10 Specifications of Plain Fabrics

Hom

Hom No.

Hlau Dia.(mm)

Lub zog

Permeability (m3 / m2h)

Warp

Hlau / cm

Welf

Hlau / cm

Flat Wire Fabric series

4106-1

0.38*0.58

16.66

0.50

15

Ntau dua lossis sib npaug li 2000

5950±500

4106-2

0.38*0.58

18

0.40/0.6

14.66

Ntau dua lossis sib npaug li 2000

4800±500

SIB 4106

0.5*0.75

14.66

0.60/0.40

12.66

Ntau dua lossis sib npaug rau 2100

6000±500

SIB 1860

0.25*1.05

9

0.60/0.90

7

Ntau dua lossis sib npaug li 2200

2100±500


Polyester tsim cov ntaub

image012image014image016image018
Duab.19. 4-tso ib txheejPic.20 8-tso ib leegDuab.21 16-shed 2.5Pic 22 20-tso triple


Daim ntawv thov:

Nws yog tsim rau cov ntawv siv tshuab thiab high-ceev ntawv ua tshuab


Table 11 Specifications of forming Fabrics

Hom

Hom No.

Hlau Dia.(mm)

Lub zog

Permeability (m3 / m2h)

Warp

Hlau / cm

Welf

Hlau / cm

4 shed ib txheej ntaub

27254

0.20

29

0.25

22

Ntau dua lossis sib npaug li 600

7500±500

27274

0.20

30

0.27

22.5

Ntau dua lossis sib npaug li 600

7500±500

31204

0.20

35

0.22

28

Ntau dua lossis sib npaug li 600

6500±500

5 shed ib txheej ntaub

27255

0.20

30

0.25

23

Ntau dua lossis sib npaug li 600

7600±500

27285

0.22

30

0.28

23

Ntau dua lossis sib npaug li 500

7800±500

31205

0.20

35

0.21

32

Ntau dua lossis sib npaug li 600

6700±500

8 shed ib txheej ntaub

25358

0.22

28

0.35

19.5

Ntau dua lossis sib npaug li 700

9000±500

25408

0.22

29.5

0.40

19

Ntau dua lossis sib npaug li 700

8500±500

27358

0.22

29

0.35

20

Ntau dua lossis sib npaug li 700

8500±500

27408

0.22

31.5

0.40

19

Ntau dua lossis sib npaug li 700

8000±500

8 shed ob txheej ntaub

56188

0.17

61.3

0.19/0.22

51.2

Ntau dua lossis sib npaug li 850

6800±500

60188

0.18

66

0.18/0.20

49

Ntau dua lossis sib npaug li 900

6000±500

62188

0.15

70.5

0.16/0.17

50.5

Ntau dua lossis sib npaug li 900

5700±500


Table 12 Specifications of forming Fabrics

Hom

Hom No.

Hlau Dia.(mm)

Lub zog

Permeability (m3 / m2h)

Warp

Hlau / cm

Welf

Hlau / cm

16 rhais ob thiab ib nrab txheej ntaub

365016

0.28

37-38

0.20,0.27/0.50,0.50

31-32

Ntau dua lossis sib npaug li 600

7500±500

424516

0.25

48-49

0.20,0.25/0.45,0.45

42-43

Ntau dua lossis sib npaug li 600

7500±500

562516

0.18

57-58

0.13,0.18/0.25,0.25

46-47

Ntau dua lossis sib npaug li 600

6500±500

563516

0.20

56-57

0.13,0.25/0.35,0.35

61-62

Ntau dua lossis sib npaug li 600

7600±500

602516

0.18

62-63

0.13,0.20/0.25,0.25

55-56

Ntau dua lossis sib npaug li 500

7800±500

603516

0.20

61-62

0.13,0.25/0.35,0.35

52-53

Ntau dua lossis sib npaug li 600

6700±500

20 shed triple txheej ntaub

563520

0.15,0.20

70

0.15,0.15/0.35/0.35

55

Ntau dua lossis sib npaug li 1600

5000±500

24-tso peb txheej ntaub

364024

0.20/0.20

42

0.20,0.17/0.40,0.40

52

Ntau dua lossis sib npaug li 1600

6500±500


Cim npe nrov: polyester hlau mesh, Tuam Tshoj, lwm tus neeg, manufacturers, hoobkas, customized
